- Storage:
- 2 x PCI Bus Master IDE Ports (Up to 4 IDE Devices)
- Supports PIO Mode 3, 4: 17MB/Sec.(Max.)
- DMA Mode 2: 22MB/Sec.(Max.)
- Rear Panel I/O Ports:
- 1 ATX PS/2 Mouse port using IRQ 12
- 1 ATX ECP/EPP Parallel port
- 2 ATX 16550 High Speed Serial Ports
- 2 USB Ports rev 1.2
- 1 ATX PS/2 Keyboard Connector
- Internal I/O Interface:
- 2 x Floppy Port (Up to 2.88MB, 3 Mode)
- 2 x Serial Ports (16550 Fast UART Compatible)
- 1 x Parallel Port (ECP, EPP Port)
- 2 x USB Ports
- 1 x IR Port
- 1 x PS/2 Mouse Port
|
Motherboard Specifications
- Model:
- Tyan S1564S Tomcat IV Motherboard
- Processor Support:
- ZIF Socket 7 for Pentium CPUs
- Intel® Pentium 75-200MHz
- Intel® Pentium MMX 166 – 233MHz
- Cyrix P120+ – P166+
- AMD K5/K6 75-233MHz
- FSB:
- Chipset:
- Memory:
- 8 x 72-Pin SIMM Sockets
- Support 8MB to 512MB Memory Capacity
- Support 4/8/16/32/64MB 72-Pin DRAM Module
- Fast Page Mode or EDO DRAM Support
- Fast Page Mode or EDO Dram
- Support EDO / FPM w/Parity / ECC Support
- Expansion Slots:
- Four 32-bit PCI Bus Mastering Slots
- Five 16-bit ISA Slots
- One Shared PCI/ISA Slot – 7 usable
- BIOS:
- Award or AMI BIOS
- With DMI, Green, Plug and Play Features
- 1M-bit Flash EPROM
|
